TOSA/ROSA
TOSA
Product Name Wavelength (nm) Rate (Gb/s) Reach (Km)
25G EML TOSA 1550 25 40
25G DML TOSA 1310,CWDM 25 30
25G FP TOSA 1310 25 0.3
10G EML TOSA 1550 10 80
10G EML TOSA 1550 10 40
10G DML TOSA 1310,CWDM 10 40
10G FP TOSA 1310 10 1.4
2.5G/1G EML TOSA 1550,DWDM 2.5,1 80
2.5G/1G DML TOSA 1310,CWDM 2.5,1 40
ROSA
Product Name Wavelength (nm) Rate (Gb/s) Reach (Km)
25G APD-TIA ROSA 1270~1610 25 40
25G PIN-TIA ROSA 1270~1610 25 20
10G APD-TIA ROSA 1270~1610 10 80
10G PIN-TIA ROSA 1270~1610 10 20
2.5G APD-TIA ROSA 1270~1610 10 80
2.5G PIN-TIA ROSA 1270~1610 2.5 20
BOSA/BiDi/Tri/Quad-OSA
BOSA/Tri-OSA/Quad-OSA
Product Name Wavelength (nm) Rate (Gb/s) Reach (Km)
XGS/10GE-PON OLT Receptacle Quad-OSA Tx:1577,1490;Rx:1270,1310 10,2.5/10,1 20
XGS/10GE-PON OLT Receptacle BOSA Tx:1270;Rx:1577 10/10 20
XGS/10GE-PON ONU Pigtail BOSA Tx:1270;Rx:1577 10/10 20
XGS/10GE-PON ONU Receptacle BOSA Tx:1270;Rx:1577 10/10 20
XG/10GE-PON OLT Receptacle BOSA Tx:1270;Rx:1577 10/1 20
XG/10GE-PON ONU Pigtail BOSA Tx:1270;Rx:1577 1/10 20
XG/10GE-PON ONU Receptacle BOSA Tx:1270;Rx:1577 1/10 20
GPON Pigtail BOSA Tx:1310;Rx:1490 1/2.5 20
GPON Pigtail Tri-OSA Tx:1310;Rx:1490,1550 1/2.5/Analog 20
EPON Pigtail BOSA Tx:1310;Rx:1490 1/1 20
BiDi
Product Name Wavelength (nm) Rate (Gb/s) Reach (Km)
25G BiDi Tx:1270;Rx:1330 Tx:1330;Rx:1270 25 20
10G BiDi Tx:1270;Rx:1330 Tx:1330;Rx:1270 10 20
1G BiDi Tx:1310;Rx:1550 Tx:1550;Rx:1310 1 20
1G BiDi Tx:1310;Rx:1490 Tx:1490;Rx: 1310 1 20
Optical Engine Series
100G LR4/CWDM4/SR4 Optical Engine
Product Name Wavelength (nm) Rate (Gb/s) Reach (Km)
100G LR4/LWDM4 Engine LWDM 100 20
100G CWDM4 Engine 1310,CWDM 100 10
